Preface
Apply to Model: UFACTORY Lite6
Joint Range:
| Joint | Range | Joint | Range |
|---|---|---|---|
| J1 | ±360° | J4 | ±360° |
| J2 | ±150° | J5 | ±124° |
| J3 | -3.5°~300° | J6 | ±360° |
Motion Parameters:
| TCP Motion | Joint Motion | |
|---|---|---|
| Speed | 0~500mm/s | 0～180°/s |
| Acceleration | 0~50000mm/s² | 0～1145°/s² |
| Jerk | 0～100000mm/s³ | 0～28647°/s³ |
- In the TCP motion (Cartesian space motion) commands (set_position () function of the SDK), If a motion command involves both position transformation and attitude transformation, the attitude rotation speed is generally calculated automatically by the system. In this situation, the specified speed parameter is the maximum linear speed, range from: 0～500mm/s.
- When the expected TCP motion only changes the attitude (roll, pitch, yaw), with position (x, y, z) remains unchanged, the specified speed is the attitude rotation speed, so the range 0 to 500 corresponds to 0 to 180 ° / s.
Unit Definition:
| Parameter | Python-SDK | Blockly | Communication Protocol |
|---|---|---|---|
| X（Y/Z） | millimeter（mm） | millimeter（mm） | millimeter（mm） |
| Roll（Pitch/Yaw） | degree（°） | degree（°） | radian（rad） |
| J1~J6 | degree（°） | degree（°） | radian（rad） |
| TCP Speed | mm/s | mm/s | mm/s |
| TCP Acceleration | mm/s² | mm/s² | mm/s² |
| TCP Jerk | mm/s³ | mm/s³ | mm/s³ |
| Joint Speed | °/s | °/s | rad/s |
| Joint Acceleration | °/s² | °/s² | rad/s² |
| Joint Jerk | °/s³ | °/s³ | rad/s³ |
